ESPECIFICACIONES TÉCNICAS


General

Device Interfaces

802.11ac/n/g/b/a Wireless LAN
10/100 Mbps Ethernet Port
Reset Button
WPS Button

LEDs

Status/WPS
3 Segment Wi-Fi Signal Strength Indicator

Standards

IEEE 802.11ac
IEEE 802.11n
IEEE 802.11g
IEEE 802.11b
IEEE 802.11a
IEEE 802.3ab

Antennas

Two external antennas ,  ,

Data Signal Rate

2.4 GHz
Up to 300 Mbps1
5 GHz
Up to 866 Mbps1


Functionality

Wireless Security

Wi-Fi Protected Access (WPA/WPA2)
WPS (PBC)

Advanced Features

D-Link One-Touch Extender Setup ,  , ,

Device Management

Supports QRS Mobile app for iPhone, iPad, iPod touch, and Android mobile devices
Web UI


Physical

Dimensions

97.9 x 50.7 x 48.7 mm (3.85 x 2.00 x 1.92 inches)

Weight

120 grams (4.23 ounces) ,  ,  ,  , ,

Power

Input: 110 to 240 V AC, 50/60 Hz ,  ,  ,

Temperature

Operating: 0 to 35 °,C (32 to 95 °,F)
Storage: -20 to 70 °,C (-4 to 158 °,F)

Humidity

Operating: 10% to 90% non-condensing
Storage: 5% to 95% non-condensing

Certifications

FCC
IC
CE2
UL
